비접촉식 3차원 측정기

Control system Non Contact three dimension
coordinate measuring machine
Measuring range 600mm (X axis)
450mm (Y axis)
150mm (Z axis)
Accuracy XY Plane : (3+200/L)㎛
Workpiece Max 150mm
Max 30kg
Drive unit Panasonic AC Servo Motors (Japan)
UWC4000i DSP Servo Control Unit
HC1 Portable Joystick & Mouse Control
Resolution 0.5 μm (0.0005mm)
Zoom Lens Motorized Zoom Lens (6.5:1)
